Extract JSON Block Screenshot

​
Overview

The Extract JSON Block finds and parses the first JSON object or array in the input text. It attempts to locate JSON data between curly braces {} or square brackets [] and parse it into a JavaScript object.

​
Inputs

​
input
string
required
The input string containing JSON data to be extracted. The block will search for the first valid JSON object or array in this string.

​
Outputs

​
output
object
The extracted and parsed JSON data as a JavaScript object. If no valid JSON is found or parsing fails, this output will be control-flow-excluded.
​
noMatch
string
If no valid JSON could be parsed, this output will contain the original input string. If JSON was successfully parsed, this output will be control-flow-excluded.

​
Example: Extracting JSON from Text

  1. Add an Extract JSON block to your flow
  2. Connect a string containing JSON data to the input
  3. The block will attempt to find and parse the first JSON object
  4. If successful, the parsed object will be available at the output port
  5. If unsuccessful, the original string will be available at the noMatch port

​
Error Handling

  • If no valid JSON is found or if parsing fails, the output port will be control-flow-excluded and the original input string will be available at the noMatch port
  • If valid JSON is found and parsed successfully, the noMatch port will be control-flow-excluded and the parsed object will be available at the output port

​
FAQ

The block can extract both JSON objects (enclosed in curly braces ) and JSON arrays (enclosed in square brackets []). It will find the first occurrence of either structure in the input string.
The block will only extract the first valid JSON object or array it finds in the input string. Subsequent JSON objects will be ignored.
If the block cannot parse valid JSON from the input string, it will output the original string to the noMatch port and control-flow-exclude the output port.

​
